Product details

Model: HEC R410A refrigerant

Introducation:

R-410A is an almost azeotropic binary mixture of HFC-32 and HFC-125(50%/.50% mass ratio). It has a floating temperature belowAt 0.2 ° C, its properties are very similar to azeotropes, and it can be regarded as a single refrigerant. This means that they do not destroy the system and its combined proportions, nor do they change in the event of a leak. The cylinder diameter cannot be too large, and the discharge volume of the compressor is not greater than 32cm3, so the piston machine can separate the composition and have dangerous compression force R-410A is used as the ultimate replacement of R-22 refrigerant air conditioning fixed system, but it cannot be applied on the original R22 equipment. It is not a substitute for R22 R-410A has been shown to improve energy efficiency by 5 to 6%, higher than R-22. It also has a higher capacity and release pressure than the R-22, enabling a more compact and compact design for air conditioning units.R-410AER22 increases the pressure by nearly 60%, but its discharge pressure and suction pressure have the same compression ratio as R22. Vapor compression can not exceed a certain space, dangerous! This is very important, so fluorination must be carried out in liquid, for it has more mechanical properties can make Angle more compact compressors, smaller diameter tubes, higher speeds and more efficient equipment, because R-410A is compatible with mineral oil or alkyl benzene oil, because R-410A will not be mixed with them. For R-410A, the specified oil is polyol (POE) oil. These oils should not be exposed to open air and should only be opened before use.
